Aquaculture Water Quality Sensor With Automatic Cleaning Brush RS485 Output

Product Categories
Xi'an Kacise Optronics Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Aquaculture Water Quality Sensor With Automatic Cleaning Brush RS485 Output

  • 1
  • 2

Brand Name : Kacise

Model Number : KWS-900

Certification : certificate of explosion-proof, CE

Place of Origin : China (Mainland)

MOQ : 0-100

Price : USD600-USD1100

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 100

Delivery Time : 5-8 working days

Packaging Details : each unit has individual box and all boxes are packed in standard packages or customers requests available

Measuring range : 0-1000NTU

Principle : Principle 90° scattered light

Output : RS485

Resolution : 0.1NTU

accurate : <5% or 0.3NTU(which is bigger)

Power supply : DC 5~12V,

Contact Now

KWS-900 online residual chlorine Sensor user manual

1. Application

Kacise ingeniously applies advanced fiber technology to the turbidity sensor, thereby endowing the sensor with significantly enhanced repeatability and stability. It is not easily influenced by ambient light coordination, ensuring accurate measurements even in various lighting conditions. The sensor is equipped with an automatic cleaning brush that functions remarkably well. This brush effectively eliminates air bubbles that might otherwise interfere with the measurement process and also reduces the adverse effects of contamination on the measurement results. With its ability for long-term online use, the sensor features longer maintenance intervals, which is highly convenient for users. Moreover, it exhibits exceptional stability, providing reliable and consistent measurements over an extended period.

2. Feature

Digital sensor, RS-485 output, support MODBUS, with automatic cleaning brush, prevent pollution, eliminate air bubbles, strong anti-interference ability, no ambient light and chromaticity, 90° scattered light principle, better fiber technology repeat-ability.

3.Technical Specifications

Item Fiber turbidity sensor Self-cleaning turbidity sensor
Model KWS-900A KWS-900B
Principle 90° scattered light
Measuring Range 0-1000NTU
Resolution 0.1NTU
Accuracy <5% or 0.3NTU(which is bigger)
Protection Rate IP68
Deepest Depth Underwater 60 meters Underwater 10 meters
Temperature Range 0 ~ 50℃
Output Support RS-485, MODBUS protocol
Power Supply DC 5~12V, current <50mA DC 5~12V, current <50mA (when not clean)
Installation Input type Input type
Size Φ22mm*120mm Φ33mm*156mm
Probe Cable Length 10 m, 5 m, 15 m and 30 m cable customizable
Self-Cleaning System No Yes
Optical Window optical fiber

Aquaculture Water Quality Sensor With Automatic Cleaning Brush RS485 Output

Aquaculture Water Quality Sensor With Automatic Cleaning Brush RS485 Output

Aquaculture Water Quality Sensor With Automatic Cleaning Brush RS485 Output

Company Information

Aquaculture Water Quality Sensor With Automatic Cleaning Brush RS485 Output

Xi'an Kacise is certified by ISO 9001-2008, GJB 9001B-2009, CE, intrinsic safety explosion-proof and isolated safety explosion-proof, etc. which assure our products are conform to the international standards.

We have been specializing in manufacturing pressure, level and flow measuring instruments and related products for 10 years. We have experienced technical and management personnel, through the efforts of our entire staff, we have become a professional measuring instrument manufacturer and solution provider. And we are continuously trying to improve product quality.

Currently, Kacise sensor is already exported to America, Spain, Australia, Chile and 20 other countries and regions, and received many favorable feedbacks. Our overseas distributers are also increasing. We regards “reasonable prices, efficient production time and good after-sales service” as our tenet, and hope to cooperate with more customers for mutual development.

We supply high quality Turbine Flow Meter, hope we can coopperate in near future by providing you suitable products, good services and reasonable prices.
